- 650W Continuous Power – Guaranteed Continuous Power from Antec
- 80 PLUS Platinum Certified – to reduce your electricity bill
- Antec Quality 7-year warranty
- 120mm Silent Fan – High-quality fan with long lifetime
- Zero RPM Manager – An advanced low voltage fan control with fan-off mode at low loads for absolute silence
- 99% + 12V – Output for maximum CPU & GPU support
- CircuitShield – Full suite of protection management
- LLC + DC to DC Design – Design with a synchronous rectification based on a DC-DC topology
- Top Japanese Heavy-Duty Caps
The new NeoECO Platinum series is ready to provide PC gamers the exceptional performance with the features of the latest ATX & EPS standard, outstanding stability, and 80 PLUS Platinum certification. The advanced thermal control with the Zero RPM mode enables to turn the fan off at low loads to provide absolute silence. With the 120 mm silent fan, the NeoEco Platinum can optimize the balance between cooling and noise. High-quality Japanese heavy-duty caps can provide your system more stable performance. The CircuitShield design serves your industry-grade protection to make your system safe in any environment.With the 7-year warranty, the NeoECO Platinum series will be the most reliable choice for professional users and PC gamers.
Japanese capacitors ensure the tightest DC stability and regulation, for reliability that you and your system can count on.
A server-class Half-Bridge LLC design with
synchronous rectification based on a DC-DC
topology to improve performance and stability.
The Zero RPM fan mode further automatically
ensures zero fan speed at low loads to reduce
plenty of noise and keep absolute silence.
The new NeoECO Platinum series from Antec
pushes the standard for excellence with the
circuit shield suite of industrial protections and
is backed by a 7-year warranty.
Features improvement for airflow
and excellent durability.
INPUT
100∼240V, 50-60Hz, 10A MAX
OUTPUT
| +3.3V | +5V | +12V | -12V | +5VSB |
| 20A | 20A | 54A | 0.3A | 2.5A |
| 100W | 648W | 3.6W | 12.5W | |
| 650W | ||||
Enables users to use only the cables which are needed
and help clear out excess cables that can obstruct and
reduce airflow.
Guaranteed 650W of Continuous Power from Antec- 100% Modular-Improves airflow and reduces clutter
- 80 PLUS® Platinum certified-Reduce your electricity bill
- PhaseWave Design-A server-class LLC design with a synchronous rectification based on a DC-DC topology
- Antec Quality 7-year warranty
- 120mm Silent Fan-Whisper-quiet high-quality fluid-dynamic bearing fan with long lifetime
- Zero RPM Manager-An advanced low voltage fan control with fan-off mode at low loads for absolute silence
- 99%+12V – Output for maximum CPU & GPU support
- CircuitShield-Full suite of industrial grade protections: OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO
- High-Quality JP capacitors achieve unprecedented tight voltage regulation & low ripple & noise to maximize your system’s performance
- 28(18+10) pin MBU socket – For possible future MBU connectors
- ATX12V 2.4-Engineered according to the newest PSU guideline and compatible with the latest CPU generation
- Delivers non-stop industrial class performance for high-end computer systems at up to 45°C ambient.
