NZXT H510i COMPACT MIDTOWER BLACK CABINET CASE

NZXT
Availability:

Out of stock


9,532 13,699

Out of stock

Compare

H510i

Taking it a step up from the H510, the H510i brings even more features to the H Series.

  • Pre-installed RGB LED Strip
  • Built-in mounting bracket for installing your GPU vertically
  • Lighting and fan control supported by CAM Smart Device V2
  • Cable routing kit with pre-installed channels and straps
  • USB 3.1 Gen2-compatible USB-C connector on the front panel
  • The clean, modern design, iconic cable management bar, and uninterrupted tempered-glass side panel showcase your stunning build.
  • Two Aer F120mm fans and removable filter on PSU intake.
  • Removable bracket designed for radiators up to 280mm
Weight 8 kg
Dimensions 42 × 21 × 46 cm
Brand

NZXT

Cabinet

color

Tech Specs

Key Specs

  • Motherboard Support

    Mini-ITX, MicroATX, ATX

  • Enclosure Type

    Compact Mid-Tower

  • Case Material

    SGCC Steel, Tempered Glass

Dimensions

  • Height

    460mm / 18.11 inches

  • Width

    210mm / 8.27 inches

  • Depth

    428mm / 16.85 inches

  • Weight

    6.8 kg / 15lbs

Compatibility & Clearance

  • Max CPU Cooler Clearance

    165mm

  • Max GPU Clearance

    321 – 381mm

  • Front Fan & Radiator Clearance

    60mm

  • Vertical GPU Clearance

    50.8mm

  • Cable Management

    19 – 23mm

Front I/O Ports

  • USB 3.2 Gen 2 Type-A

    1

  • USB 3.2 Gen 1 Type-C

    1

  • Headset Audio Jack

    1

Smart Device

  • Fan Channels

    3 (10W max per channel)

  • NZXT RGB Connector

    2 (Support up to 40 LEDs)

Expansion Slots

  • Standard

    7

  • Vertical

    2

Drive Bays

  • 2.5″

    2 + 1

  • 3.5″

    2 + 1

Fan Support

  • Front

    2 x 120mm / 2 x 140mm

  • Top

    1 x 120mm / 1 x 140mm

  • Rear

    1 x 120mm

  • Filters

    All air intakes

Radiator Support

  • Front

    280mm

  • Top

  • Rear

    120mm

Fan Specs

  • Model

    Aer P 120mm (Case Version)

  • Speed

    1,200 ± 200RPM

  • Airflow

    50.42 CFM

  • Noise

    28 dBA

  • Fan Connector

    3-pin

General

  • Warranty

    2 Years

  • Model Number

    CA-H510i-W1

  • UPC

    815671014726

  • EAN

    5060301695027
