Includes: Basic UPS signalling RS-232 cable, CD with software, DC cable, Rack mounting brackets, Stabilization/wall mounting feet, USB cable, User manual
-29%
| Weight | 15 kg |
|---|---|
| Brand | APC |
| Warranty | 2 Years |
Max Configurable Power (Watts)
1.6kWatts / 2.0kVA
Output Voltage Note
Configurable for 220 : 230 or 240 nominal output voltage
Efficiency at Full Load
88.0 %
Output Voltage Distortion
3 %
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages
220 V, 240 V
Load Crest Factor
3 : 1
Topology
Double conversion online
Waveform type
Sine wave
Bypass
Internal bypass (automatic and manual)
Input
Input frequency
40 – 70 Hz Auto sensing
Input voltage range for main operations
110 – 280 Half load, 160 – 280 Full loadV
Efficiency at Full Load
88.0 %
Other Input Voltages
220 V, 240 V
Batteries & Runtime
Battery type
External battery system
Nominal Battery Voltage
72 V
Battery Charge Power (Watts)
700 Watts
Efficiency
Communications & Management
Interface Port(s)
DB-9 RS-232, Intelligent Smart Slot, USB
Control panel
Multifunction LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO)
Yes
Surge Protection and Filtering
Surge energy rating
600Joules
Physical
Maximum Height
86MM, 8.6CM
Maximum Width
438MM, 43.8CM
Maximum Depth
462MM, 46.2CM
Net Weight
9.8KG
Shipping weight
13.9KG
Shipping Height
240MM, 24.0CM
Shipping Width
545MM, 54.5CM
Shipping Depth
700MM, 70.0CM
Color
Black
Environmental
Operating Temperature
0 – 40 °C
Operating Relative Humidity
0 – 95 (Non-condensing) %
Operating Elevation
0 – 3000meters
Storage Temperature
-20 – 60 °C
Storage Relative Humidity
0 – 95 (Non-condensing) %
Storage Elevation
0 – 15000meters
Audible noise at 1 meter from surface of unit
50.0dBA
Online thermal dissipation
745.0BTU/hr
Protection Class
IP20
Conformance
Approvals
BIS
