| Weight | 1 kg |
|---|---|
| Brand | ECS |
| Warranty | 2 Years |
| Brand | ECS |
|---|---|
| Model | BAT-I2/J1900 (1.0) |
| Combo Type | Motherboard / CPU Combo |
| Motherboard | ESC BAT-I2 (V1.0) |
|---|---|
| CPU | Intel Celeron Processor J1900 |
| CPU Socket Type | Onboard Intel Bay Trail |
|---|---|
| Supported CPU Technologies | Hyper-Threading Technology |
| Number of Memory Slots | 1 x SO-DIMM socket |
|---|---|
| Memory Standard | DDR3 |
| Maximum Memory Supported | 8GB |
| Mini Card Slots | 1 X Mini PCI Express X1 slot(s) for Wi-Fi /Blutooth modules |
|---|
| SATA | 2 x SATA 3.0Gb/s |
|---|
| Audio Chipset | VIA VT1705 |
|---|---|
| Audio Channels | 6 Channels |
| LAN Chipset | Realtek 8111G |
|---|---|
| LAN Speed | 10/100/1000Mbps |
| PS/2 | 1 x PS/2 keyboard/mouse port |
|---|---|
| Video Ports | 1 x D-Sub (VGA) port(s) |
| HDMI | 1 x HDMI |
| USB 1.1/2.0 | 4 x USB 2.0 |
| USB 3.0 | 1 x USB 3.0 |
| Audio Ports | 1 x Audio port (Line Out/Line In/Mic In) |
| Onboard USB | 2 x USB 2.0 header – Support additional 4 USB ports |
|---|---|
| Other Connectors | 1 x RJ-45 port 1 x 4-pin CPU_FAN connector with smart fan 1 x 4-pin SYS_FAN connector with smart fan 1 x Front Panel MIC/Speaker out header 1 x Front Panel switch/LED header 1 x CLR_CMOS header 2 x Serial port header (COM) 1 x Parallel port header (LPT) 1 x LVDS connector (optional) |
| Features | Applied Solid Capacitor for CPU VRM to ensure a longer lifespan for system
ECS Durathon Technology ensure the stability, reliability and performance of system. Dual Display design for multiple output support Integrated Printer (LPT) port / header to expand functionality Microsoft Windows 8 Certified Intel VRD 12 Ready Supports DirectX 11 to enhance graphical performance Supports HDMI 1.4a Technology ( resolution up to 1920X1200 ) and HDCP function Free Bundle: Norton Internet Security ,CyberLink PowerDVD, CyberLink PowerDirector 9, Muzee, Google Chrome, Magix with trial version |
|---|
| Form Factor | Mini ITX |
|---|---|
| Dimensions (W x L) | 6.69″ x 6.69″ |
